Nationallab ProfiLine Pegasus type ultra low temperature freezers

Request a price


The outer casing of the equipment is white powder-coated steel, and the interior is easily cleanable stainless steel. Even large coolers can be easily moved on the 4 large-diameter, heavy-duty castors (2 of which can be fixed). Smaller devices have feet.

The microprocessor controller with a user-friendly menu system enables convenient operation. The illuminated graphic display displays clearly visible, large characters.

A visual and acoustic alarm warns in the event of a power failure, sensor error, door opening, and exceeding the set peak/low temperature. It is possible to connect an external alarm, and the equipment is also prepared for GSM alarms.

Additional features: integrated data acquisition device (software included), RS485 and USB interface. Drawer boxes and compartments can be placed in the storage chambers (see options).

The coolers in the last two rows of the table have a dual cooling system (independent, separate cooling circuits). If one cooling circuit fails, the other cooling circuit can also keep the temperature below -70°C.

More details

**PLPE 6290 and *PLPE 7286 types have two independent cooling systems (separate compressors). The advantage of double cooling tend type ultra-deep freezers is that in the event of a failure of one of the cooling circuits, even in emergency mode, approx. The system can maintain -70 - 80°C.

Nationallab ProfiLine Pegasus type ultra-deep freezers

Specifications: Temperature range Volume Consumption Chamber dimensions mm External dimensions mm
PLPE 0186 -40 – 90  °C 7 liters 0.19 kW/hour 150 x 143 x 310 400 x 630 x 665
PLPE 0486 -60 -  86 oC 35 liters 0.20 kW/hour 330 × 355 × 300  490 × 650 × 670
PLPE 0686 -40 – 86  °C 55 liters 0.26 kW/hour 360 × 505 × 310  600 x 700 x 815
PLPE 1086 -40 – 86  °C 91 liters 0.32 kW/hour 430 × 425 × 625 595 × 695 × 825
PLPE 1286 -40 – 86  °C 115 liters 0.32 kW/hour 360 × 493 × 530 950 × 725 × 810
PLPE 4286 -40 – 86  °C 393 liters 0.50 kW/hour 440 x 595 x 1.275 720 x 885 x 1.990
**PLPE 6290 -40 – 90  °C 556 liters, two cooling system 0.86 kW/hour 640 × 595 x 1.345 920 × 880 × 1.990
*PLPE 7286 -40 – 86  °C 642 liters, two cooling system 1.30 kW/hour 750 x 595 x 1.285 1030 x 880 x 2090

code
Volume
Name
Cooling range
net price
amount
in stock
317.PLPE0186
7 l
PLPE 0186 ultra low temperature freezer
-40 – -86 °C
Request a price
pc

"Temperature range: -40 to -86C. Interior: stainless steel. 12 cm thick thermal insulation, no interior door. External surface: painted (white) steel. Control: - digital display with text messages, - visual and audio signal (power failure, door opening, in case of exceeding the set temperature limit), - GSM module and CO2 backup system preparation, - voltage-free contact (for external alarm) - door lock with key - adjustable height legs Internal dimensions: 150 × 143 × 310 mm. External dimensions: 400 × 630 × 665 mm Number of compressors: 1 Weight: 54 kg The storage boxes shown in the picture are not part of the offer, they can be ordered as an option."

"Temperature range: -40 to -86C. Interior: stainless steel. 12 cm thick thermal insulation, no interior door. External surface: painted (white) steel. Control: - digital display with text messages, - visual and audio signal (power failure, door opening, in case of exceeding the set temperature limit), - GSM module and CO2 backup system preparation, - voltage-free contact (for external alarm) - door lock with key - adjustable height legs Internal dimensions: 150 × 143 × 310 mm. External dimensions: 400 × 630 × 665 mm Number of compressors: 1 Weight: 54 kg The storage boxes shown in the picture are not part of the offer, they can be ordered as an option."

317.PLPE0486
35 l
PLPE 0486 ultra low temperature freezer
-60 – -86 °C
Request a price
pc

"Temperature range: -60 to -80°C. Interior: stainless steel. 8 cm thick thermal insulation, no interior door. External surface: painted (white) steel. Static cooling, manual melting. Control: - digital display with text messages, - visual and audio signal (power failure, door opening, in case of exceeding the set temperature limit), - GSM module and CO2 backup system preparation, - voltage-free contact (for external alarm) - door lock with key Gross volume: 35 liters. Internal dimensions: 330x355x300 mm. External dimensions: 490x650x670 mm Number of compressors: 1 Noise level: <50 pcs Energy consumption: approx. 5 kWh/24h Weight: 60 kg The rack system shown in the picture is not part of the offer, it can be ordered as an option."

"Temperature range: -60 to -80°C. Interior: stainless steel. 8 cm thick thermal insulation, no interior door. External surface: painted (white) steel. Static cooling, manual melting. Control: - digital display with text messages, - visual and audio signal (power failure, door opening, in case of exceeding the set temperature limit), - GSM module and CO2 backup system preparation, - voltage-free contact (for external alarm) - door lock with key Gross volume: 35 liters. Internal dimensions: 330x355x300 mm. External dimensions: 490x650x670 mm Number of compressors: 1 Noise level: <50 pcs Energy consumption: approx. 5 kWh/24h Weight: 60 kg The rack system shown in the picture is not part of the offer, it can be ordered as an option."

317.PLPE0686
55 l
PLPE 0686 ultra low temperature freezer
-40 – -86 °C
Request a price
pc

"Temperature range: -60 to -86°C. Interior: stainless steel. 12 cm thick thermal insulation, no interior door. External surface: painted (white) steel. Control: - digital display with text messages, - visual and audio signal (power failure, door opening, in case of exceeding the set temperature limit), - GSM module and CO2 backup system preparation, - voltage-free contact (for external alarm) - door lock with key Gross volume: 55 liters. Internal dimensions: 360 × 505 × 310 mm. External dimensions: 600 × 700 × 815 mm Number of compressors: 1 Weight: 80 kg The rack system shown in the picture is not part of the offer, it can be ordered as an option."

"Temperature range: -60 to -86°C. Interior: stainless steel. 12 cm thick thermal insulation, no interior door. External surface: painted (white) steel. Control: - digital display with text messages, - visual and audio signal (power failure, door opening, in case of exceeding the set temperature limit), - GSM module and CO2 backup system preparation, - voltage-free contact (for external alarm) - door lock with key Gross volume: 55 liters. Internal dimensions: 360 × 505 × 310 mm. External dimensions: 600 × 700 × 815 mm Number of compressors: 1 Weight: 80 kg The rack system shown in the picture is not part of the offer, it can be ordered as an option."

317.PLPE1086
91 l
PLPE 1086 ultra low temperature freezer
-40 – -86 °C
Request a price
pc

"Temperature range: -60 to -86°C. Interior: stainless steel. 8 cm thick thermal insulation, no interior door. External surface: painted (white) steel. Control: - digital display with text messages, - visual and audio signal (power failure, door opening, in case of exceeding the set temperature limit), - GSM module and CO2 backup system preparation, - voltage-free contact (for external alarm) - door lock with key - 48-hour backup battery mode for control and alarms - 35,000-capacity data recorder (1.5 years of data recording) Preparation for an external monitoring system. With 2 stainless steel adjustable shelves. USB port, door lock with key Gross volume: 91 liters. Internal dimensions: 430 × 425 × 625 mm. External dimensions: 595 × 695 × 825 mm Number of compressors: 1 Weight: 60 kg The rack system shown in the picture is not part of the offer, it can be ordered as an option."

"Temperature range: -60 to -86°C. Interior: stainless steel. 8 cm thick thermal insulation, no interior door. External surface: painted (white) steel. Control: - digital display with text messages, - visual and audio signal (power failure, door opening, in case of exceeding the set temperature limit), - GSM module and CO2 backup system preparation, - voltage-free contact (for external alarm) - door lock with key - 48-hour backup battery mode for control and alarms - 35,000-capacity data recorder (1.5 years of data recording) Preparation for an external monitoring system. With 2 stainless steel adjustable shelves. USB port, door lock with key Gross volume: 91 liters. Internal dimensions: 430 × 425 × 625 mm. External dimensions: 595 × 695 × 825 mm Number of compressors: 1 Weight: 60 kg The rack system shown in the picture is not part of the offer, it can be ordered as an option."

317.PLPE1286
115 l
PLPE 1286 ultra low temperature freezer
-40 – -86 °C
Request a price
pc

"Temperature range: -40 to -86°C. Interior: stainless steel. 12 cm thick thermal insulation, thermally insulated internal doors, heated door frame. External surface: painted (white) steel. Control: - digital display with text messages, - visual and audio signal (power failure, door opening, in case of exceeding the set temperature limit), - data collector, - GSM module and CO2 backup system preparation, - USB + RS 485 port. - door lock with key Gross volume: 115 liters. With internal doors: 2/2 (with 2 × 260 mm height) Internal dimensions: 360 × 493 × 530 mm. External dimensions: 950 × 725 × 810 mm The front legs of the cabinet allow you to adjust the height, and two castors at the back. Number of compressors: 1 Weight: 100 kg"

"Temperature range: -40 to -86°C. Interior: stainless steel. 12 cm thick thermal insulation, thermally insulated internal doors, heated door frame. External surface: painted (white) steel. Control: - digital display with text messages, - visual and audio signal (power failure, door opening, in case of exceeding the set temperature limit), - data collector, - GSM module and CO2 backup system preparation, - USB + RS 485 port. - door lock with key Gross volume: 115 liters. With internal doors: 2/2 (with 2 × 260 mm height) Internal dimensions: 360 × 493 × 530 mm. External dimensions: 950 × 725 × 810 mm The front legs of the cabinet allow you to adjust the height, and two castors at the back. Number of compressors: 1 Weight: 100 kg"

317.PLPE4286
393 l
PLPE 4286 ultra low temperature freezer
-40 – -86 °C
Request a price
pc

"Temperature range: -40 to -86°C. Chamber material: stainless steel 12 cm thick thermal insulation, 5 pcs. insulated inner door, heated door frame. External surface: zinc-coated and then painted (white) steel. Control: - digital display with text messages, - visual and audio signal (power failure, door opening, in case of exceeding the set temperature limit), - data collector, - Can be equipped with GSM module and CO2 back-up system, - USB + RS 485 port. - door lock with key Gross volume: 393 liters. Number of shelves: 4 + the bottom plate, with internal doors Internal compartment size: 440 x 595 x 255 mm. External dimensions: 720 x 885 x 1,990 mm Mounted on castors, 2 of which can be fixed. Number of compressors: 1 Energy consumption: 12.0 kWh/24 hours. Weight: 175 kg"

"Temperature range: -40 to -86°C. Chamber material: stainless steel 12 cm thick thermal insulation, 5 pcs. insulated inner door, heated door frame. External surface: zinc-coated and then painted (white) steel. Control: - digital display with text messages, - visual and audio signal (power failure, door opening, in case of exceeding the set temperature limit), - data collector, - Can be equipped with GSM module and CO2 back-up system, - USB + RS 485 port. - door lock with key Gross volume: 393 liters. Number of shelves: 4 + the bottom plate, with internal doors Internal compartment size: 440 x 595 x 255 mm. External dimensions: 720 x 885 x 1,990 mm Mounted on castors, 2 of which can be fixed. Number of compressors: 1 Energy consumption: 12.0 kWh/24 hours. Weight: 175 kg"

317.PLPE6290
556 l
**PLPE 6286 ultra low temperature freezer
-40 – -90 °C
Request a price
pc

"with gross volume. Temperature range: -40 to -86°C, 0.1°C resolution 2 compressors, with 2 separate (independent) cooling circuits. Chamber material: stainless steel 12 cm thick thermal insulation, thermally insulated internal doors (5 pcs.), heated door frame, door lock with key, vacuum valve, white painted outer cover. Control: - digital display with text messages, - visual and audio signal (power failure, door opening, in case of exceeding the set temperature limit), - data collector, with USB connector, RS-485 port - voltage-free contact, - Prepared for GSM module and CO2 backup system, Number of shelves: 4 (+the bottom sheet) Noise level: <55 dbA Internal dimensions: 640x595x1.345 mm WxDxH) The total height is divided into 4 parts of 255 mm and one part of 325 mm (bottom). External dimensions: 920×885×1990 mm. Refrigerant: EP 88 Lock with key, mounted on rollers (2 of which can be fixed). Weight: approx. 210 kg"

"with gross volume. Temperature range: -40 to -86°C, 0.1°C resolution 2 compressors, with 2 separate (independent) cooling circuits. Chamber material: stainless steel 12 cm thick thermal insulation, thermally insulated internal doors (5 pcs.), heated door frame, door lock with key, vacuum valve, white painted outer cover. Control: - digital display with text messages, - visual and audio signal (power failure, door opening, in case of exceeding the set temperature limit), - data collector, with USB connector, RS-485 port - voltage-free contact, - Prepared for GSM module and CO2 backup system, Number of shelves: 4 (+the bottom sheet) Noise level: <55 dbA Internal dimensions: 640x595x1.345 mm WxDxH) The total height is divided into 4 parts of 255 mm and one part of 325 mm (bottom). External dimensions: 920×885×1990 mm. Refrigerant: EP 88 Lock with key, mounted on rollers (2 of which can be fixed). Weight: approx. 210 kg"

317.PLPE7286
642 l
*PLPE 7286 ultra low temperature freezer
-40 – -86 °C
Request a price
pc

"with net volume. Gross volume: 642 liters. Temperature range: -40 to -86°C, 0.1°C resolution 2 compressors, with 2 separate (independent) cooling circuits. Chamber material: stainless steel 12 cm thick thermal insulation, thermally insulated internal doors (5 pcs.), heated door frame, door lock with key, vacuum valve, white painted outer cover. Control: microprocessor - digital display with text messages, - visual and audio signal (power failure, door opening, in case of exceeding the set temperature limit), - built-in logger with USB connector - voltage-free contact, - Suitable for receiving a GSM module, but the module must be ordered separately. - USB + RS 485 ports - optional CO2 Back-up system available Number of shelves: 4 (+the bottom sheet) Noise level: <55 dbA Internal dimensions, per compartment: 750x595x260 mm. External dimensions: 1030x880x1990 mm. Refrigerant: EP 88 Mounted on castors, 2 of which can be fixed Weight: 242 kg"

"with net volume. Gross volume: 642 liters. Temperature range: -40 to -86°C, 0.1°C resolution 2 compressors, with 2 separate (independent) cooling circuits. Chamber material: stainless steel 12 cm thick thermal insulation, thermally insulated internal doors (5 pcs.), heated door frame, door lock with key, vacuum valve, white painted outer cover. Control: microprocessor - digital display with text messages, - visual and audio signal (power failure, door opening, in case of exceeding the set temperature limit), - built-in logger with USB connector - voltage-free contact, - Suitable for receiving a GSM module, but the module must be ordered separately. - USB + RS 485 ports - optional CO2 Back-up system available Number of shelves: 4 (+the bottom sheet) Noise level: <55 dbA Internal dimensions, per compartment: 750x595x260 mm. External dimensions: 1030x880x1990 mm. Refrigerant: EP 88 Mounted on castors, 2 of which can be fixed Weight: 242 kg"
